Security researchers have uncovered vulnerabilities affecting the firmware of Supermicro server products.

Discovered by the Eclypsium team, these vulnerabilities affect both older and newer models of Supermicro products, but the vendor is working on addressing the issues.

These vulnerabilities do not put the safety of Supermicro products at direct risk, as they can only be exploited via malicious software/code (aka malware) already running on a system. Nevertheless, exploiting these vulnerabilities allows the malware to obtain an almost permanent foothold on infected systems by gaining the ability to survive server OS reinstalls by hiding in the hardware's firmware.

Malware can modify Descriptor Region settings

The first of the flaws uncovered by Eclypsium researchers is not an actual vulnerability in the firmware's code, but in the configuration of some Supermicro products.

Researchers say that some of these products come with firmware that uses an improper setting for the "Descriptor Region."

The Descriptor Region is a security feature of Intel-based chipsets. This setting tells the chipset what areas of its own flash storage external parties can access to store data such as firmware or configuration files.

According to Eclypsium researchers, some Supermicro products had an incorrectly set Descriptor Region that allowed software running on the OS (such as malware) to modify the Descriptor Region and then tamper with local firmware.

"Eclypsium researchers have observed vulnerable descriptor access controls through runtime examination of various server firmware models," the Eclypsium team wrote in a report published today.

"This manual analysis uncovered multiple server models that allowed writes to the flash descriptor from host software. According to Supermicro, some of the products we reviewed date back to 2008 and are currently EOL and no longer supported."

No firmware authentication for some products

But while modifying the Descriptor Region setting may be possible on some Supermicro products, tampering with the local firmware isn't as easy as it sounds, as several security mechanisms prevent malicious actors from altering a computer or server's most important code.

Here is where the second series of issues that the Eclypsium team discovered came into play.

"We have observed insecure firmware updates through runtime examination of various systems. This manual analysis uncovered that Supermicro X9DRi-LN4F+ and X10SLM-F systems did not securely authenticate firmware updates," the research team said.

"We confirmed this result by intentionally modifying the binary in official Supermicro firmware images and observing that the system firmware still accepted and installed the modified package."

No firmware rollback protection

But the issues didn't stop here, and the Eclypsium team also noted a lack of anti-rollback protections for firmware images.

This anti-rollback protection is crucial for situations where the vendor checks for firmware authenticity.

A firmware anti-rollback protection would prevent attackers from replacing newer firmware with an older (legitimate) firmware image that contains flaws that attackers can exploit and gain a foothold on all-of-a-sudden vulnerable systems.

Supermicro working on fixes

Eclypsium says it notified Supermicro about all the issues they discovered in the firmware of their products back in January.

"Supermicro has been supportive of our efforts and prioritized understanding and mitigating the issues we have discovered," Eclypsium says,

"For the current generation of products, Supermicro indicated that they have already implemented a signed firmware update for several products and are making this update generally available for all future systems.

"Similarly, for OEM customers who require rollback capability for their customized and locked firmware versions to ensure business continuity, Supermicro indicated that they are supporting anti-rollback as an option for their X11 generation firmware.

"The SPI flash descriptor is read-only on most boards and we are helping Supermicro identify specific models where this may be incorrectly set."

Impacted models

For owners of Supermicro server hardware, Eclypsium has released instructions on how to check the descriptor access controls of their own systems.

These procedures require installing and running the CHIPSEC Framework, a tool co-created by one of Eclypsium founders while working for Intel. All the server owner has to do is to run the following command:

chipsec_main -m common.spi_access
If this test fails, then the current descriptor values offer no protection, because they can be changed.

If an attacker were to exploit insecure firmware updates, the obvious goal would be to somehow alter the firmware. This enables very stealthy and persistent malware that can bypass many security controls. However, it may be possible to detect such malware (if it has not taken explicit steps to prevent this).

To defend against these attacks, it is possible to collect hashes of firmware modules. These can be validated against a whitelist from firmware provided by the vendor. If unexpected changes are discovered, expert analysis will be needed to manually assess them.

Bleeping Computer has sent a request for comment to Supermicro days before this article's publication. We asked Supermicro to confirm the Eclypsium research and inquired for a list of Supermicro platforms affected by the reported security issues, but we have not heard back before this article's publication time.

Until Supermicro responds or publishes an official security advisory with a list of affected models, Eclypsium CEO and Founder Yuriy Bulygin was kind enough to share with Bleeping Computer the list of Supermicro products they believe to be affected.

"For the missing UEFI update protections, it appears that a majority or all of X8, X9, X10 generation server products, and a majority of X11 generation server products are affected," Bulygin told Bleeping Computer via email. "We don’t know exact number of affected models but we found 1184 unique firmware images for at least 233 unique X8-X11 server models."

"For the flash descriptor issue we found close to 500 firmware images with this issue which translates to about 110 different models (some of them may be old). The list is below:"

X11SSZ
X11SSV
X11SSQL
X11SSQ
X11SSN
X11SRM
X11SRA
X11SBA
X11SAT
X11SAE_M
X11SAE
X10SRW
X10SRM
X10SRL
X10SRI
X10SRH
X10SRG
X10SRD
X10SRA
X10SDVT
X10SDVF
X10SDE
X10SDDF
X10SBA
X10QRH
X10DSN
X10DSCP
X10DSC
X10DRX
X10DRWN
X10DRW
X10DRUX
X10DRUL
X10DRU
X10DRTS
X10DRTPS
X10DRTL
X10DRTH
X10DRTB
X10DRT
X10DRS
X10DRLN
X10DRLC
X10DRL
X10DRI1
X10DRH4
X10DRH
X10DRGO
X10DRGH
X10DRG
X10DRFR
X10DRFG
X10DRFF
X10DRDL
X10DRD
X10DRC
X10DGO
X10DDWN
X10DDWI
X10DDW4
X10DDW3
X10DAX
X10DALI
X10DAL
X10DAI
B10DRT
B10DRI
B10DRG
X9SAE
X9DRTH
X9DRGQF
X9DRFFP
X9DRF
X9DBL
X8SIU
X8SIT
X8SIL
X8SIE
X8SIA
K1SPI
K1SPES
C9X299
C7Z97OC
C7Z97MF
C7Z87OC
C7Z370L
C7Z370I
C7Z270P
C7Z270M
C7Z270L
C7Z270CG
C7Z270C
C7Z170OCE
C7Z170O
C7Z170
C7X99OC
C7Q270
C7H270
C7B250
B1SD2TF
B1SA4
B1DRI
A2SAV
A2SAP
A2SAN
A1SRM
A1SAM
A1SAI1
A1SAI
A1SA
