Trojan + Virus; Computer Unbootable, no C:


  • This topic is locked This topic is locked
40 replies to this topic

#1 RayN81

RayN81

  • Members
  • 42 posts
  • OFFLINE
  •
  • Local time:02:01 AM

Posted 22 May 2011 - 06:50 PM

Hi

I run windows 7.

First problem - McAfee recently picked up a trojan (possibly Alureon, but I can't remember the name) and attempted to remove it but failed because the file was not found.

Second problem - A few minutes after, icons started disappearing off my desktop and I get a message saying that there were some errors detected with my IDE/SATA drivers and that I had to reboot. This leads me to believe that I have the Window's Recovery virus.

My PC froze, so I rebooted, only to encounter a bigger problem - my pc is now unbootable (possibly from Alureon). I see the Windows 7 loading screen, a flash of a blue screen, and my computer resets.

I have tried the following, but to no avail:
- I booted from the Windows 7 installation disk to try a repair, but there are no drives detected (ie - no C:), so I can neither repair nor start a fresh installation.
- While in the windows installation, I tried selecting a driver from the Windows 7 installation disk (atapi.sys) and my Motherboard installation disk (nvstor32.sys), but I get an error message saying that the driver is not related to my drives.
- I checked my BIOS and saw that my HD is detected but my Primary IDE master and slave are disabled.
- I plugged my HD into a USB adapter and connected it into my laptop. It recognises that a USB HD has been plugged in but the drive does not show in My Computer. When I right clicked My Computer and selected 'Manage', the drive appears under Disk Management, but shows up as invalid.

The above is the extent of my IT capabilities. The majority of the help/fixes I see require you to at least be able to see your C:, so I'm at a loss on what to do next. My preference is to salvage what I can as there are some documents I have worked on over the last few days that have not been backed up yet.

I would appreciate any help. Thanks.

Raymond

BC AdBot (Login to Remove)




#2 AustrAlien

AustrAlien

    Inquisitor


  • BC Advisor
  • 6,772 posts
  • OFFLINE
  •
  • Gender:Male
  • Location:Cowra NSW Australia
  • Local time:02:01 AM

Posted 22 May 2011 - 07:33 PM

Hello and :welcome: to the BC forums.

Please sit tight and be patient.

I have requested that an experienced helper who specialises in malware-related un-bootable computers respond to your topic.

Thank you.
AustrAlien
Google is my friend. Make Google your friend too.

Posted Image

#3 RayN81

RayN81
  • Topic Starter

  • Members
  • 42 posts
  • OFFLINE
  •
  • Local time:02:01 AM

Posted 22 May 2011 - 08:09 PM

Thanks for the prompt response, AustrAlien. Much appreciated.

#4 JSntgRvr

JSntgRvr

    Master Surgeon General


  • Malware Response Team
  • 11,453 posts
  • OFFLINE
  •
  • Gender:Male
  • Location:Puerto Rico
  • Local time:12:01 PM

Posted 23 May 2011 - 01:06 AM

Hi, :welcome:

Lets give it a try.

We will need to view the system status from an external environment. You will need a USB drive and a CD to burn. There will be several steps to follow.

Download GETxPUD.exe to the desktop of your clean computer
  • Run GETxPUD.exe
  • A new folder will appear on the desktop.
  • Open the GETxPUD folder and click on the get&burn.bat
  • The program will download xpud_0.9.2.iso, and upon finished will open BurnCDCC ready to burn the image.
  • Click on Start and follow the prompts to burn the image to a CD.
  • Next download driver.sh to your USB drive
  • Also Download Query.exe to the USB drive. In your working computer, navigate to the USB drive and click on the Query.exe. A folder and a file, query.sh, will be extracted.
  • Lastly, download Dumpit by noahdfear to the USB drive.
  • Remove the USB & CD and insert them in the sick computer
  • Boot the Sick computer with the CD you just burned
  • The computer must be set to boot from the CD
  • In some computers you need to tap F12 and choose to boot from the CD, in others is the Esc key. Please consult your computer's documentation.
  • Follow the prompts
  • A Welcome to xPUD screen will appear
  • Press File
  • Expand mnt
  • sda1,2...usually corresponds to your HDD
  • sdb1 is likely your USB
  • Click on the folder that represents your USB drive (sdb1 ?)
  • Confirm that you see driver.sh that you downloaded there
  • Press Tool at the top
  • Choose Open Terminal
  • Type bash driver.sh
  • Press Enter
  • After it has finished a report will be located on your USB drive named report.txt
  • Then type bash driver.sh -af
  • Press Enter
  • You will be prompted to input a filename.
  • Type the following:

    Winlogon.exe

  • Press Enter
  • If successful, the script will search for this file.
  • After it has completed the search enter the next file to be searched
  • Type the following:

    volsnap.sys

  • Press Enter
  • If successful, the script will search for this file.
  • After it has completed the search enter the next file to be searched
  • Type the following:

    explorer.exe

  • Press Enter
  • After it has completed the search enter the next file to be searched
  • Type the following:

    Userinit.exe

  • Press Enter
  • After the search is completed type Exit and press Enter.
  • After it has finished a report will be located in the USB drive as filefind.txt
  • While still in the Open Terminal, type bash query.sh
  • Press Enter
  • After it has finished a report will be located in the USB drive as RegReport.txt
  • Then, close the Open Terminal window. Confirm that you see the file dumpit in your USB drive and double click on it.
  • After it has finished a report will be located in your USB drive named mbr.zip
  • Attach this file to a reply
  • Plug the USB back into the clean computer, except for the mbr.zip file, post the contents of the report.txt, filefind.txt and RegReport.txt in your next reply. The mbr.zip file must be attached to your reply.

No request for help throughout private messaging will be attended.

If I have helped you, consider making a donation to help me continue the fight against Malware!


#5 RayN81

RayN81
  • Topic Starter

  • Members
  • 42 posts
  • OFFLINE
  •
  • Local time:02:01 AM

Posted 23 May 2011 - 03:21 AM

JSntgRvr, thank you for your quick response.

I had trouble adding attachments - I don't seem to have the ability to. I have uploaded it to fileserve and have attached the link below.

As instructed, here are the contents of the respective text files:

======================================== Report.txt ===============================================
Mon May 23 15:18:52 UTC 2011
Driver report for /mnt/sda3/Windows/System32/drivers
7c28b63e4c9e5c3be7ffe53789593619 volsnap.sys has NO Company Name!

fbce2f43185104ae8bf4d32571b19203 1394bus.sys
Microsoft Corporation

6d2aca41739bfe8cb86ee8e85f29697d 1394ohci.sys
Microsoft Corporation

98d81ca942d19f7d9153b095162ac013 acpipmi.sys
Microsoft Corporation

f0e07d144c8685b8774bc32fc8da4df0 acpi.sys
Microsoft Corporation

21e785ebd7dc90a06391141aac7892fb adp94xx.sys
Adaptec

0c676bc278d5b59ff5abd57bbe9123f2 adpahci.sys
Adaptec

7c7b5ee4b7b822ec85321fe23a27db33 adpu320.sys
Adaptec

ddc040fdb01ef1712a6b13e52afb104c afd.sys
Microsoft Corporation

57ec4aef73660166074d8f7f31c0d4fd agilevpn.sys
Microsoft Corporation

507812c3054c21cef746b6ee3d04dd6e AGP440.sys
Microsoft Corporation

0d40bcf52ea90fc7df2aeab6503dea44 aliide.sys
Acer Laboratories

3c6600a0696e90a463771c7422e23ab5 AMDAGP.SYS
Microsoft Corporation

cd5914170297126b6266860198d1d4f0 amdide.sys
Microsoft Corporation

ff258424f0b2ef25eb98f04ee386e6e3 amdiox86.sys
Advanced Micro Devices

00dda200d71bac534bf56a9db5dfd666 amdk8.sys
Microsoft Corporation

3cbf30f5370fda40dd3e87df38ea53b6 amdppm.sys
Microsoft Corporation

19ce906b4cdc11fc4fef5745f33a63b6 amdsata.sys
Advanced Micro Devices

ea43af0c423ff267355f74e7a53bdaba amdsbs.sys
AMD Technologies

869e67d66be326a5a9159fba8746fa70 amdxata.sys
Advanced Micro Devices

feb834c02ce1e84b6a38f953ca067706 appid.sys
Microsoft Corporation

5d6f36c46fd283ae1b57bd2e9feb0bc7 arcsas.sys
Adaptec

2932004f49677bd84dbc72edb754ffb3 arc.sys
Adaptec

d48659bb24c48345d926ecb45c1ebdf5 ASACPI.sys
tH((VS_VERSION_INFO%?(aStringFileInfodbCommentsCompanyNameRFileDescriptionATKACPIUtility@FileVersion,,,bInternalNameATK$LegalCopyright(LegalTrademarksbOriginalFilenameATKPrivateBuildJProductNameATKACPIUtility@ProductVersion,,,SpecialBuildDVarFileInfo$Translationtx'

19166026a93206f9c6a8cd3a1f010ae4 ASUSHWIO.SYS

add2ade1c2b285ab8378d2daaf991481 asyncmac.sys
Microsoft Corporation

338c86357871c167a96ab976519bf59e atapi.sys
Microsoft Corporation

bca15585efdde7eba8568bdfb75983a3 ataport.sys
Microsoft Corporation

b01751cc563aecac09bbe36aaa21fbef athr.sys
Atheros Communications

95b1e9804ca10d096c0383f7c6684950 AtihdW73.sys
Advanced Micro Devices

8fd111119be6924b1b8c3976fac1b535 atikmdag.sys
ATI Technologies

c9b705ff53b15dd71f6a4d4f45396edd atikmpag.sys
Advanced Micro Devices

bd8869eb9cde6bbe4508d869929869ee b57nd60x.sys
Broadcom Corporation

2b8ee031fd700ab942ebe60665440e83 battc.sys
Microsoft Corporation

505506526a9d467307b3c393dedaf858 beep.sys
Microsoft Corporation

2287078ed48fcfc477b05b20cf38f36f blbdrive.sys
Microsoft Corporation

9a5c671b7fbae4865149bb11f59b91b2 bowser.sys
Microsoft Corporation

9f9acc7f7ccde8a15c282d3f88b43309 BrFiltLo.sys
Brother Industries

56801ad62213a41f6497f96dee83755a BrFiltUp.sys
Brother Industries

77361d72a04f18809d0efb6cceb74d4b bridge.sys
Microsoft Corporation

845b8ce732e67f3b4133164868c666ea BrSerId.sys
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries
Brother Industries

203f0b1e73adadbbb7b7b1fabd901f6b BrSerWdm.sys
Brother Industries

bd456606156ba17e60a04e18016ae54b BrUsbMdm.sys
Brother Industries

af72ed54503f717a43268b3cc5faec2e BrUsbSer.sys
Brother Industries

ed3df7c56ce0084eb2034432fc56565a bthmodem.sys
Microsoft Corporation

1a231abec60fd316ec54c66715543cec bxvbdx.sys
Broadcom Corporation

77ea11b065e0a8ab902d78145ca51e10 cdfs.sys
Microsoft Corporation

ba6e70aa0e6091bc39de29477d866a77 cdrom.sys
Microsoft Corporation

3fe3fe94a34df6fb06e6418d0f6a0060 circlass.sys
Microsoft Corporation

a6388a5abf92c7927c085db0a958125f Classpnp.sys
Microsoft Corporation

dea805815e587dad1dd2c502220b5616 CmBatt.sys
Microsoft Corporation

c537b1db64d495b9b4717b4d6d9edbf2 cmdide.sys
CMD Technology

1b675691ed940766149c93e8f4488d68 cng.sys
Microsoft Corporation

a6023d3823c37043986713f118a89bee compbatt.sys
Microsoft Corporation

f1724ba27e97d627f808fb0ba77a28a6 CompositeBus.sys
Microsoft Corporation

b7efef22ff426ec4158a177cb3b558d3 crashdmp.sys
Microsoft Corporation

2c4ebcfc84a9b44f209dff6c6e6c61d1 crcdisk.sys
Microsoft Corporation

27c9490bdd0ae48911ab8cf1932591ed csc.sys
Microsoft Corporation

8e09e52ee2e3ceb199ef3dd99cf9e3fb dfsc.sys
Microsoft Corporation

1a050b0274bfb3890703d490f330c0da discache.sys
Microsoft Corporation

3d8bdf695ba1569995027ad904f847e9 Diskdump.sys
Microsoft Corporation

565003f326f99802e68ca78f2a68e9ff disk.sys
Microsoft Corporation

8b30250d573a8f6b4bd23195160d8707 djsvs.sys
Adaptec

b918e7c5f9bf77202f89e1a9539f2eb4 drmkaud.sys
Microsoft Corporation

27f9288af019e6daca281ede51ff5928 drmk.sys
Microsoft Corporation

5428227d4730ebdfc842e9fb593f8c8a Dumpata.sys
Microsoft Corporation

62a63ef2f3053b461cb327e4d69aaa74 dumpfve.sys
Microsoft Corporation

5fcd3320aae71506b43f9e12e4e72172 dxapi.sys
Microsoft Corporation

1679a4669326cb1a67cc95658d273234 dxgkrnl.sys
Microsoft Corporation

cf519d46e5b8bde8d7ba981ba9a174cd dxgmms1.sys
Microsoft Corporation

1b6242b20cb56f85a158e67f09ee84fe dxg.sys
Microsoft Corporation

0ed67910c8c326796faa00b2bf6d9d3c elxstor.sys
Emulex

8fc3208352dd3912c94367a206ab3f11 errdev.sys
Microsoft Corporation

024e1b5cac09731e4d868e64dbfb4ab0 evbdx.sys
Broadcom Corporation

2dc9108d74081149cc8b651d3a26207f exfat.sys
Microsoft Corporation

7e0ab74553476622fb6ae36f73d97d35 fastfat.sys
Microsoft Corporation

e817a017f82df2a1f8cfdbda29388b29 fdc.sys
Microsoft Corporation

6cf00369c97f3cf563be99be983d13d8 fileinfo.sys
Microsoft Corporation

42c51dc94c91da21cb9196eb64c45db9 filetrace.sys
Microsoft Corporation

87907aa70cb3c56600f1c2fb8841579b flpydisk.sys
Microsoft Corporation

7520ec808e0c35e0ee6f841294316653 fltMgr.sys
Microsoft Corporation

1a16b57943853e598cff37fe2b8cbf1d fsdepends.sys
Microsoft Corporation

a574b4360e438977038aae4bf60d79a2 fs_rec.sys
Microsoft Corporation

d909075fa72c090f27aa926c32cb4612 fssfltr.sys
Microsoft Corporation

dafbd9fe39197495aed6d51f3b85b5d2 fvevol.sys
Microsoft Corporation

5a50439aac7bb7763237a88f0f3a337f FWPKCLNT.SYS
Microsoft Corporation

65ee0c7a58b65e74ae05637418153938 GAGP30KX.SYS
Microsoft Corporation

8182ff89c65e4d38b2de4bb0fb18564e GEARAspiWDM.sys
GEAR Software

c44e3c2bab6837db337ddee7544736db hcw85cir.sys
Hauppauge Computer Works

717a2207fd6f13ad3e664c7d5a43c7bf hdaudbus.sys
Microsoft Corporation

3530cad25deba7dc7de8bb51632cbc5f HdAudio.sys
Microsoft Corporation

1d58a7f3e11a9731d0eaaaa8405acc36 hidbatt.sys
Microsoft Corporation

89448f40e6df260c206a193a4683ba78 hidbth.sys
Microsoft Corporation

b682e1cc0fdc7ac04b71d1fa9a07ef21 hidclass.sys
Microsoft Corporation

cf50b4cf4a4f229b9f3c08351f99ca5e hidir.sys
Microsoft Corporation

6c26122f1931d4d7810240f32ddce890 hidparse.sys
Microsoft Corporation

25072fb35ac90b25f9e4e3bacf774102 hidusb.sys
Microsoft Corporation

295fdc419039090eb8b49ffdbb374549 HpSAMD.sys
Hewlett-Packard

c531c7fd9e8b62021112787c4e2c5a5a http.sys
Microsoft Corporation

8305f33cde89ad6c7a0763ed0b5a8d42 hwpolicy.sys
Microsoft Corporation

f151f0bdc47f4a28b1b20a0818ea36d6 i8042prt.sys
Microsoft Corporation

71f1a494fedf4b33c02c4a6a28d6d9e9 iaStorV.sys
Intel Corporation

4173ff5708f3236cf25195fecd742915 iirsp.sys
Intel Corp

7dda9b43ebccdebfa608afcc99528edc iLokDrvr.sys
ttTVS_VERSION_INFObbnbbn?baStringFileInfoBNCompanyNamePACEAnti-Piracy,Inc.fFileDescriptionWindowsUSBiLokDeviceDriverbFileVersion...:rInternalNameiLokDrvr.sysSLegalCopyrightCopyright-,PACEAnti-Piracy,Inc.,AllRightsReserved,CONFIDENTIALBrOriginalFilenameiLokDrvr.sysbProductNameiLok®<bProductVersion...DVarFileInfo$Translationt<assemblyxm

a0f12f2c9ba6c72f3987ce780e77c130 intelide.sys
Microsoft Corporation

3b514d27bfc4accb4037bc6685f766e0 intelppm.sys
Microsoft Corporation

709d1761d3b19a932ff0238ea6d50200 ipfltdrv.sys
Microsoft Corporation

e4454b6c37d7ffd5649611f6496308a7 IPMIDrv.sys
Microsoft Corporation

a5fa468d67abcdaa36264e463a7bb0cd ipnat.sys
Microsoft Corporation

9f7e491fb0ba0f9e370163834fc1fe31 irda.sys
Microsoft Corporation

42996cff20a3084a56017b7902307e9f irenum.sys
Microsoft Corporation

1f32bb6b38f62f7df1a7ab7292638a35 isapnp.sys
Microsoft Corporation

994ebb45c4b438e1f6ea0b958ae9b9a3 ivusb.sys
?banStringFileInfobFCompanyNameInitioCorporation-FileDescriptionInitioDefaultVendorSpecificDeviceDriver>FileVersion...vInternalNameIniven.sysLegalCopyrightInitioCorporation-.Allrightsreserved.>vOriginalFilenameIniven.sysz-ProductNameInitioDefaultVendorSpecificDeviceDriverBProductVersion...DVarFileInfo$TranslationtFOMB@DS}T(CB

adef52ca1aeae82b50df86b56413107e kbdclass.sys
Microsoft Corporation

3d9f0ebf350edcfd6498057301455964 kbdhid.sys
Microsoft Corporation

e36a061ec11b373826905b21be10948f ksecdd.sys
Microsoft Corporation

365c6154bbbc5377173f1ca7bfb6cc59 ksecpkg.sys
Microsoft Corporation

9e79e2354301783d5e0d48411c2a7466 ks.sys
Microsoft Corporation

f7611ec07349979da9b0ae1f18ccc7a6 lltdio.sys
Microsoft Corporation

eb119a53ccf2acc000ac71b065b78fef lsi_fc.sys
LSI Corporation

dc9dc3d3daa0e276fd2ec262e38b11e9 lsi_sas2.sys
LSI Corporation

8ade1c877256a22e49b75d1cc9161f9c lsi_sas.sys
LSI Corporation

0a036c7d7cab643a7f07135ac47e0524 lsi_scsi.sys
LSI Corporation

6703e366cc18d3b6e534f5cf7df39cee luafv.sys
Microsoft Corporation

b689282843c9c7a1684823704f52286f MAudioProducer.sys
tt@tPt`tpt+(%'h+XXVS_VERSION_INFOnvnv?tStringFileInfobLCompanyNameAvidTechnology,Inc.fFileDescriptionM-AudioUSBAudioDriver(WDM)bFileVersion...LegalCopyright-AvidTechnology,Inc.AllRightsReserved.DVarFileInfo$Translationt(`*

ef08d2ebe3eabba43cc57eee001027b6 mcd.sys
Microsoft Corporation

0fff5b045293002ab38eb1fd1fc2fb74 megasas.sys
LSI Corporation

dcbab2920c75f390caf1d29f675d03d6 MegaSR.sys
LSI Corporation

f001861e5700ee84e2d4e52c712f4964 modem.sys
Microsoft Corporation

79d10964de86b292320e9dfe02282a23 monitor.sys
Microsoft Corporation

fb18cc1d4c2e716b6b903b0ac0cc0609 mouclass.sys
Microsoft Corporation

2c388d2cd01c9042596cf3c8f3c7b24d mouhid.sys
Microsoft Corporation

921c18727c5920d6c0300736646931c2 mountmgr.sys
Microsoft Corporation

2af5997438c55fb79d33d015c30e1974 mpio.sys
Microsoft Corporation

ad2723a7b53dd1aacae6ad8c0bfbf4d0 mpsdrv.sys
Microsoft Corporation

b1be47008d20e43da3adc37c24cdb89d mrxdav.sys
Microsoft Corporation

e593d45024a3fdd11e93cc4a6ca91101 mrxsmb10.sys
Microsoft Corporation

a9f86c82c9cc3b679cc3957e1183a30f mrxsmb20.sys
Microsoft Corporation

b4c76ef46322a9711c7b0f4e21ef6ea5 mrxsmb.sys
Microsoft Corporation

4326d168944123f38dd3b2d9c37a0b12 msahci.sys
Microsoft Corporation

455029c7174a2dbb03dba8a0d8bddd9a msdsm.sys
Microsoft Corporation

daefb28e3af5a76abcc2c3078c07327f msfs.sys
Microsoft Corporation

3e1e5767043c5af9367f0056295e9f84 mshidkmdf.sys
Microsoft Corporation

0a4e5757ae09fa9622e3158cc1aef114 msisadrv.sys
Microsoft Corporation

ed46c223ae46c6866ab77cdc41c404b7 msiscsi.sys
Microsoft Corporation

8c0860d6366aaffb6c5bb9df9448e631 mskssrv.sys
Microsoft Corporation

3ea8b949f963562cedbb549eac0c11ce mspclock.sys
Microsoft Corporation

f456e973590d663b1073e9c463b40932 mspqm.sys
Microsoft Corporation

0e008fc4819d238c51d7c93e7b41e560 msrpc.sys
Microsoft Corporation

fc6b9ff600cc585ea38b12589bd4e246 mssmbios.sys
Microsoft Corporation

b42c6b921f61a6e55159b8be6cd54a36 mstee.sys
Microsoft Corporation

33599130f44e1f34631cea241de8ac84 MTConfig.sys
Microsoft Corporation

159fad02f64e6381758c990f753bcc80 mup.sys
Microsoft Corporation

0e1787aa6c9191d3d319e8bafe86f80c ndiscap.sys
Microsoft Corporation

23759d175a0a9baaf04d05047bc135a8 ndis.sys
Microsoft Corporation

e4a8aec125a2e43a9e32afeea7c9c888 ndistapi.sys
Microsoft Corporation

b30ae7f2b6d7e343b0df32e6c08fce75 ndisuio.sys
Microsoft Corporation

267c415eadcbe53c9ca873dee39cf3a4 ndiswan.sys
Microsoft Corporation

af7e7c63dcef3f8772726f86039d6eb4 ndproxy.sys
Microsoft Corporation

80b275b1ce3b0e79909db7b39af74d51 netbios.sys
Microsoft Corporation

dd52a733bf4ca5af84562a5e2f963b91 netbt.sys
Microsoft Corporation

e87fe6daf5a1b0845a0e376f4269f75b netio.sys
Microsoft Corporation

1d85c4b390b0ee09c7a46b91efb2c097 nfrd960.sys
IBM Corp

1db262a9f8c087e8153d89bef3d2235f npfs.sys
Microsoft Corporation

e9a0a4d07e53d8fea2bb8387a3293c58 nsiproxy.sys
Microsoft Corporation

187002ce05693c306f43c873f821381f ntfs.sys
Microsoft Corporation

f9756a98d69098dca8945d62858a812c null.sys
Microsoft Corporation

5a0983915f02bae73267cc2a041f717d NV_AGP.SYS
Microsoft Corporation

603b0c9bb86f7b3efb88a482c6663ec4 nvhda32v.sys
NVIDIA Corporation

b5e37e31c053bc9950455a257526514b nvm62x32.sys
NVIDIA Corporation

d22e432e402499ac264a113d7168b91f nvmf6232.sys
NVIDIA Corporation

f1b0bed906f97e16f6d0c3629d2f21c6 nvraid.sys
NVIDIA Corporation

be9039422a5ce976c03c5e2cf20106be nvsmu.sys
NVIDIA Corporation

4520b63899e867f354ee012d34e11536 nvstor.sys
NVIDIA Corporation

26384429fcd85d83746f63e798ab1480 nwifi.sys
Microsoft Corporation

08a70a1f2cdde9bb49b885cb817a66eb ohci1394.sys
Microsoft Corporation

6270ccae2a86de6d146529fe55b3246a pacer.sys
Microsoft Corporation

2ea877ed5dd9713c5ac74e8ea7348d14 parport.sys
Microsoft Corporation

ff4218952b51de44fe910953a3e686b9 partmgr.sys
Microsoft Corporation

eb0a59f29c19b86479d36b35983daadc parvdm.sys
Microsoft Corporation

afe86f419014db4e5593f69ffe26ce0a pciide.sys
Microsoft Corporation

ede040d666ff81bf1978d0f19f799e7a pciidex.sys
Microsoft Corporation

c858cb77c577780ecc456a892e7e7d0f pci.sys
Microsoft Corporation

f396431b31693e71e8a80687ef523506 pcmcia.sys
Microsoft Corporation

250f6b43d2b613172035c6747aeeb19f pcw.sys
Microsoft Corporation

9e0104ba49f4e6973749a02bf41344ed PEAuth.sys
Microsoft Corporation

d72708c9f49500c13d7d067e169b7715 portcls.sys
Microsoft Corporation

85b1e3a0c7585bc4aae6899ec6fcf011 processr.sys
Microsoft Corporation

ab95ecf1f6659a60ddc166d8315b0751 ql2300.sys
QLogic Corporation

b4dd51dd25182244b86737dc51af2270 ql40xx.sys
QLogic Corporation

584078ca1b95ca72df2a27c336f9719d qwavedrv.sys
Microsoft Corporation

30a81b53c766d0133bb86d234e5556ab rasacd.sys
Microsoft Corporation

d9f91eafec2815365cbe6d167e4e332a rasl2tp.sys
Microsoft Corporation

0fe8b15916307a6ac12bfb6a63e45507 raspppoe.sys
Microsoft Corporation

631e3e205ad6d86f2aed6a4a8e69f2db raspptp.sys
Microsoft Corporation

44101f495a83ea6401d886e7fd70096b rassstp.sys
Microsoft Corporation

835d7e81bf517a3b72384bdcc85e1ce6 rdbss.sys
Microsoft Corporation

0d8f05481cb76e70e1da06ee9f0da9df rdpbus.sys
Microsoft Corporation

1e016846895b15a99f9a176a05029075 RDPCDD.sys
Microsoft Corporation

c5ff95883ffef704d50c40d21cfb3ab5 rdpdr.sys
Microsoft Corporation

5a53ca1598dd4156d44196d200c94b8a RDPENCDD.sys
Microsoft Corporation

44b0a53cd4f27d50ed461dae0c0b4e1f RDPREFMP.sys
Microsoft Corporation

801371ba9782282892d00aadb08ee367 rdpwd.sys
Microsoft Corporation

4ea225bf1cf05e158853f30a99ca29a7 rdyboost.sys
Microsoft Corporation

b4090006a82eeb608c358ab5d37de85a rmcast.sys
Microsoft Corporation

7400cfab5cf36f2294e80b3f3bda3ebc RNDISMP.sys
Microsoft Corporation

564297827d213f52c7a3a2ff749568ca rootmdm.sys
Microsoft Corporation

032b0d36ad92b582d869879f5af5b928 rspndr.sys
Microsoft Corporation

34ee0c44b724e3e4ce2eff29126de5b5 sbp2port.sys
Microsoft Corporation

a95c54b2ac3cc9c73fcdf9e51a1d6b51 scfilter.sys
Microsoft Corporation

f9882099e58ecf8b0e1c7afa5d2cc56d scsiport.sys
Microsoft Corporation

90a3935d05b494a5a39d37e71f09a677 secdrv.sys
Macrovision Corporation

9ad8b8b515e3df6acd4212ef465de2d1 serenum.sys
Microsoft Corporation

5fb7fcea0490d821f26f39cc5ea3d1e2 serial.sys
Microsoft Corporation

79bffb520327ff916a582dfea17aa813 sermouse.sys
Microsoft Corporation

9f976e1eb233df46fce808d9dea3eb9c sffdisk.sys
Microsoft Corporation

932a68ee27833cfd57c1639d375f2731 sffp_mmc.sys
Microsoft Corporation

a0708bbd07d245c06ff9de549ca47185 sffp_sd.sys
Microsoft Corporation

db96666cc8312ebc45032f30b007a547 sfloppy.sys
Microsoft Corporation

2565cac0dc9fe0371bdce60832582b2e SISAGP.SYS
Microsoft Corporation

a9f0486851becb6dda1d89d381e71055 sisraid2.sys
Silicon Integrated Systems

3727097b55738e2f554972c3be5bc1aa sisraid4.sys
Silicon Integrated Systems

3e21c083b8a01cb70ba1f09303010fce smb.sys
Microsoft Corporation

2e467e6ca8e0a140c08011844c0d3936 smclib.sys
Microsoft Corporation

95cf1ae7527fb70f7816563cbc09d942 spldr.sys
Microsoft Corporation

d16d818e9930a6e5b4f6476dd0998d1a spsys.sys
Microsoft Corporation

cdddec541bc3c96f91ecb48759673505 sptd.sys
Duplex Secure

14c44875518ae1c982e54ea8c5f7fe28 srv2.sys
Microsoft Corporation

07a14223b0a50e76ade003fdf95d4fec srvnet.sys
Microsoft Corporation

4a9b0f215de2519e2363f91df25c1e97 srv.sys
Microsoft Corporation

db32d325c192b801df274bfd12a7e72b stexstor.sys
Promise Technology

32c8e15e6f1ef98949a96451d42cec70 storport.sys
Microsoft Corporation

d5751969dc3e4b88bf482ac8ec9fe019 storvsc.sys
Microsoft Corporation

45b44fc9e5ac0db02b19d515ee809de5 stream.sys
Microsoft Corporation

e58c78a848add9610a4db6d214af5224 swenum.sys
Microsoft Corporation

949c35bf4ae6c110a924ab5e2175dda7 tape.sys
Microsoft Corporation

e64444523add154f86567c469bc0b17f tcpipreg.sys
Microsoft Corporation

bb7f39c31c4a4417fd318e7cd184e225 tcpip.sys
Microsoft Corporation

52639c994fe3cd975bfe7428b939b320 tdi.sys
Microsoft Corporation

1875c1490d99e70e449e3afae9fcbadf tdpipe.sys
Microsoft Corporation

7551e91ea999ee9a8e9c331d5a9c31f3 tdtcp.sys
Microsoft Corporation

cb39e896a2a83702d1737bfd402b3542 tdx.sys
Microsoft Corporation

c36f41ee20e6999dbf4b0425963268a5 termdd.sys
Microsoft Corporation

5815ae5ef8519066f19e575d67f6f191 TPkd.sys
aDTPKD:Deviceloadfailed:%.rnhVS_VERSION_INFObbnbbn?baStringFileInfoBNCompanyNamePACEAnti-Piracy,Inc.RFileDescriptionInterLoksystemfilebFileVersion...tInternalNameTPkd.sysSLegalCopyrightCopyright-,PACEAnti-Piracy,Inc.,AllRightsReserved,CONFIDENTIAL:tOriginalFilenameTPkd.sysbProductNameInterLok®<bProductVersion...DVarFileInfo$Translationt<assemblyxm

98ae6fa07d12cb4ec5cf4a9bfa5f4242 tssecsrv.sys
Microsoft Corporation

3e461d890a97f9d4c168f5fda36e1d00 tunnel.sys
Microsoft Corporation

750fbcb269f4d7dd2e420c56b795db6d UAGP35.SYS
Microsoft Corporation

09cc3e16f8e5ee7168e01cf8fcbe061a udfs.sys
Microsoft Corporation

44e8048ace47befbfdc2e9be4cbc8880 ULIAGPKX.SYS
Microsoft Corporation

049b3a50b3d646baeeee9eec9b0668dc umbus.sys
Microsoft Corporation

7550ad0c6998ba1cb4843e920ee0feac umpass.sys
Microsoft Corporation

b71da871254d96d0349639d03e4c1cc1 usb8023.sys
Microsoft Corporation

d4fb6ecc60a428564ba8768b0e23c0fc usbaapl.sys
Apple

2190f65ec7e9ae7a301e01e4261acef8 USBCAMD2.sys
Microsoft Corporation

47d88f155eb4e4be60ebd76ac8d17db7 USBCAMD.sys
Microsoft Corporation

c31ae588e403042632dc796cf09e30b0 usbccgp.sys
Microsoft Corporation

04ec7cec62ec3b6d9354eee93327fc82 usbcir.sys
Microsoft Corporation

675c1d745f68343f372897f761f999e3 usbd.sys
Microsoft Corporation

e4c436d914768ce965d5e659ba7eebd8 usbehci.sys
Microsoft Corporation

bdcd7156ec37448f08633fd899823620 usbhub.sys
Microsoft Corporation

eb2d819a639015253c871cda09d91d58 usbohci.sys
Microsoft Corporation

3d0074a19d16a9944be32ee1ffbbb554 usbport.sys
Microsoft Corporation

797d862fe0875e75c7cc4c1ad7b30252 usbprint.sys
Microsoft Corporation

fb9f340ecacdaeb939372cc543e72c6d usbrpm.sys
Microsoft Corporation

1c4287739a93594e57e2a9e6a3ed7353 USBSTOR.SYS
Microsoft Corporation

22480bf4e5a09192e5e30ba4dde79fa4 usbuhci.sys
Microsoft Corporation

b5f6a992d996282b7fae7048e50af83a usbvideo.sys
Microsoft Corporation

a059c4c3edb09e07d21a8e5c0aabd3cb vdrvroot.sys
Microsoft Corporation

17c408214ea61696cec9c66e388b14f3 vgapnp.sys
Microsoft Corporation

8e38096ad5c8570a6f1570a61e251561 vga.sys
Microsoft Corporation

3be6e1f3a4f1afec8cee0d7883f93583 vhdmp.sys
Microsoft Corporation

c829317a37b4bea8f39735d4b076e923 VIAAGP.SYS
Microsoft Corporation

e02f079a6aa107f06b16549c6e5c7b74 viac7.sys
Microsoft Corporation

e43574f6a56a0ee11809b48c09e4fd3c viaide.sys
VIA Technologies

15c126d1b55814b9e5cab10a9c1f4c67 videoprt.sys
Microsoft Corporation

ec2bbab4b84d0738c6c83d2234dc36fe VMBusHID.sys
Microsoft Corporation

379b349f65f453d2a6e75ea6b7448e49 vmbus.sys
Microsoft Corporation

5423d8437051e89dd34749f242c98648 vms3cap.sys
Microsoft Corporation

957e346ca948668f2496a6ccf6ff82cc vmstorfl.sys
Microsoft Corporation

384e5a2aa49934295171e499f86ba6f3 volmgr.sys
Microsoft Corporation

b5bb72067ddddbbfb04b2f89ff8c3c87 volmgrx.sys
Microsoft Corporation

7c28b63e4c9e5c3be7ffe53789593619 volsnap.sys

9dfa0cc2f8855a04816729651175b631 vsmraid.sys
VIA Technologies

90567b1e658001e79d7c8bbd3dde5aa6 vwifibus.sys
Microsoft Corporation

7090d3436eeb4e7da3373090a23448f7 vwififlt.sys
Microsoft Corporation

a3f04cbea6c2a10e6cb01f8b47611882 vwifimp.sys
Microsoft Corporation

de3721e89c653aa281428c8a69745d90 wacompen.sys
Microsoft Corporation

692a712062146e96d28ba0b7d75de31b wanarp.sys
Microsoft Corporation

cb45a417c8ef7ba6bac67edcdded8700 watchdog.sys
Microsoft Corporation

d6efaf429fd30c5df613d220e344cce7 wdcsam.sys
tH'$$VS_VERSION_INFOaStringFileInfo`bZCompanyNameWesternDigitalTechnologiesz+LegalCopyright©-WesternDigitalTechnologiesx(FileDescriptionWDSCSIArchitectureModel(SAM)drivervFileVersion,,,vInternalNameSAMdriver>vOriginalFilenamewdcsam.sysHProductNameWDExternalStorageDVarFileInfo$Translationt*

9950e3d0f08141c7e89e64456ae7dc73 Wdf01000.sys
Microsoft Corporation

fe7a7675c26fe936226641ef32ae9bb5 WdfLdr.sys
Microsoft Corporation

1112a9badacb47b7c0bb0392e3158dff wd.sys
Microsoft Corporation

8b9a943f3b53861f2bfaf6c186168f79 wfplwf.sys
Microsoft Corporation

5cf95b35e59e2a38023836fff31be64c wimmount.sys
Microsoft Corporation

d41f4ea6727415013405c7ffdd250dd8 winhv.sys
Microsoft Corporation

30fc6e5448d0cbaaa95280eeef7fedae winusb.sys
Microsoft Corporation

0217679b8fca58714c3bf2726d2ca84e wmiacpi.sys
Microsoft Corporation

9a5b1059fe015db5269fbb25acbf841d wmilib.sys
Microsoft Corporation

6db3276587b853bf886b69528fdb048c ws2ifsl.sys
Microsoft Corporation

6f9b6c0c93232cff47d0f72d6db1d21e WUDFPf.sys
Microsoft Corporation

f91ff1e51fca30b3c3981db7d5924252 WUDFRd.sys
Microsoft Corporation


======================================== FileFind.txt ===============================================

Search results for winlogon.exe

37cdb7e72eb66ba85a87cbe37e7f03fd /mnt/sda3/Windows/System32/winlogon.exe
279.0K Oct 28 2009

8ec6a4ab12b8f3759e21f8e3a388f2cf /mnt/sda3/Windows/winsxs/x86_microsoft-windows-winlogon_31bf3856ad364e35_6.1.7600.16385_none_6f99573a36451166/winlogon.exe
279.0K Jul 14 2009

37cdb7e72eb66ba85a87cbe37e7f03fd /mnt/sda3/Windows/winsxs/x86_microsoft-windows-winlogon_31bf3856ad364e35_6.1.7600.16447_none_6fc699643622d177/winlogon.exe
279.0K Oct 28 2009

3babe6767c78fbf5fb8435feed187f30 /mnt/sda3/Windows/winsxs/x86_microsoft-windows-winlogon_31bf3856ad364e35_6.1.7600.20560_none_703394514f56f7c2/winlogon.exe
279.0K Oct 28 2009


Search results for volsnap.sys

7c28b63e4c9e5c3be7ffe53789593619 /mnt/sda3/Windows/System32/drivers/volsnap.sys
239.6K Jul 14 2009

58df9d2481a56edde167e51b334d44fd /mnt/sda3/Windows/System32/DriverStore/FileRepository/volume.inf_x86_neutral_29364d30156a24ca/volsnap.sys
239.6K Jul 14 2009

58df9d2481a56edde167e51b334d44fd /mnt/sda3/Windows/winsxs/x86_volume.inf_31bf3856ad364e35_6.1.7600.16385_none_158d0da45d68903e/volsnap.sys
239.6K Jul 14 2009


Search results for explorer.exe

2af58d15edc06ec6fdacce1f19482bbf /mnt/sda3/Windows/explorer.exe
2.5M Feb 26 05:33

b95eeb0f4e5efbf1038a35b3351cf047 /mnt/sda3/Windows/winsxs/x86_microsoft-windows-explorer_31bf3856ad364e35_6.1.7600.16404_none_51e07e31dad00878/explorer.exe
2.5M Aug 3 2009

2626fc9755be22f805d3cfa0ce3ee727 /mnt/sda3/Windows/winsxs/x86_microsoft-windows-explorer_31bf3856ad364e35_6.1.7600.16450_none_51a66d6ddafc2ed1/explorer.exe
2.5M Oct 31 2009

2af58d15edc06ec6fdacce1f19482bbf /mnt/sda3/Windows/winsxs/x86_microsoft-windows-explorer_31bf3856ad364e35_6.1.7600.16768_none_51a3a583dafd0cef/explorer.exe
2.5M Feb 26 05:33

9ff6c4c91a3711c0a3b18f87b08b518d /mnt/sda3/Windows/winsxs/x86_microsoft-windows-explorer_31bf3856ad364e35_6.1.7600.20500_none_526619d4f3f142e6/explorer.exe
2.5M Aug 3 2009

c76153c7eca00fa852bb0c193378f917 /mnt/sda3/Windows/winsxs/x86_microsoft-windows-explorer_31bf3856ad364e35_6.1.7600.20563_none_52283b2af41f3691/explorer.exe
2.5M Oct 31 2009

255cf508d7cfb10e0794d6ac93280bd8 /mnt/sda3/Windows/winsxs/x86_microsoft-windows-explorer_31bf3856ad364e35_6.1.7600.20910_none_525b5180f3f95373/explorer.exe
2.5M Feb 26 05:51

8b88ebbb05a0e56b7dcc708498c02b3e /mnt/sda3/Windows/winsxs/x86_microsoft-windows-explorer_31bf3856ad364e35_6.1.7601.17567_none_5389023fd8245f84/explorer.exe
2.5M Feb 25 05:30

0fb9c74046656d1579a64660ad67b746 /mnt/sda3/Windows/winsxs/x86_microsoft-windows-explorer_31bf3856ad364e35_6.1.7601.21669_none_54149f9ef14031fc/explorer.exe
2.5M Feb 26 05:19

15bc38a7492befe831966adb477cf76f /mnt/sda3/Windows/winsxs/x86_microsoft-windows-explorer_31bf3856ad364e35_6.1.7600.16385_none_518afd35db100430/explorer.exe
2.5M Jul 14 2009


Search results for userinit.exe

6de80f60d7de9ce6b8c2ddfdf79ef175 /mnt/sda3/Windows/System32/userinit.exe
25.5K Jul 14 2009

6de80f60d7de9ce6b8c2ddfdf79ef175 /mnt/sda3/Windows/winsxs/x86_microsoft-windows-userinit_31bf3856ad364e35_6.1.7600.16385_none_dbff103933038d7c/userinit.exe
25.5K Jul 14 2009


======================================== RegReport.txt ===============================================

<empty>

======================================== MBR.zip attachment ===============================================
MBR.zip

#6 JSntgRvr

JSntgRvr

    Master Surgeon General


  • Malware Response Team
  • 11,453 posts
  • OFFLINE
  •
  • Gender:Male
  • Location:Puerto Rico
  • Local time:12:01 PM

Posted 23 May 2011 - 02:05 PM

The zip file was empty.

Lets try this fix manually.

  • Boot to xPUD
  • Press File
  • Expand mnt
  • Browse to the /mnt/sda3/Windows/System32/DriverStore/FileRepository/volume.inf_x86_neutral_29364d30156a24ca/volsnap.sys file. Right click on it and select "Copy"
  • Then browse to the /mnt/sda3/Windows/System32/drivers folder. Right click on an empty space in this folder and select "Paste". Overwrite the existing file.
  • Attempt to boot in Normal Mode.

Let me know the outcome.

No request for help throughout private messaging will be attended.

If I have helped you, consider making a donation to help me continue the fight against Malware!


#7 RayN81

RayN81
  • Topic Starter

  • Members
  • 42 posts
  • OFFLINE
  •
  • Local time:02:01 AM

Posted 23 May 2011 - 06:31 PM

Hi JSntgRvr

I did the above but it did not work. Still see a flash of blue before my pc reboots.

I re-ran the above test - xPUD shows the mbr.zip file to be 0 bytes.

#8 JSntgRvr

JSntgRvr

    Master Surgeon General


  • Malware Response Team
  • 11,453 posts
  • OFFLINE
  •
  • Gender:Male
  • Location:Puerto Rico
  • Local time:12:01 PM

Posted 23 May 2011 - 07:08 PM

Remove the filefind.txt file from the USB drive.

Boot to xPUD

  • Press File
  • Expand mnt
  • Select the folder the represent your USB drive and make sure you see the driver.sh file
  • Press Tool at the top
  • Choose Open Terminal
  • Then type bash driver.sh -af
  • Press Enter
  • You will be prompted to input a filename.
  • Type the following:

    volsnap.sys

  • Press Enter
  • After the search is completed type Exit and press Enter.
  • After it has finished a report will be located in the USB drive as filefind.txt

Post the new filefind.txt in your reply.

Close the Open Terminal.

=============================================================

Browse to the /mnt/sda3/Windows folder. See if there is a minidump folder within. If present, copy this file to the USB drive. In order to attach this to a reply, in a working computer right click on the folder and select Send to -> Compressed (zipped) folder. That should produce a zip folder. Attach this folder to a reply.

=============================================================

Boot the computer normally and tap on F8 during startup until you get to the advanced menu. Select the option not to restart on boot failure. Then let it boot. That should give you the exact error at startup within the blue screen. Please write down the exact error message and paste it on your next reply.

============================================================

How many hard drives are in that computer? Can you tell if the sda3 is the drive where the Windows 7 operating system is?

Edited by JSntgRvr, 23 May 2011 - 07:10 PM.

No request for help throughout private messaging will be attended.

If I have helped you, consider making a donation to help me continue the fight against Malware!


#9 RayN81

RayN81
  • Topic Starter

  • Members
  • 42 posts
  • OFFLINE
  •
  • Local time:02:01 AM

Posted 23 May 2011 - 07:59 PM

Hi JSntgRvr

To answer your question, there is only one hard disk, but it has several partitions in it. I'm not sure how to tell if sd3 is the drive where Windows is installed, but given the folders in sd3 - Program Files, My Documents, etc; I'm guessing it is.

==========filefind.txt ==================
Search results for volsnap.sys

58df9d2481a56edde167e51b334d44fd /mnt/sda3/Windows/System32/drivers/volsnap.sys
239.6K Jul 14 2009

58df9d2481a56edde167e51b334d44fd /mnt/sda3/Windows/System32/DriverStore/FileRepository/volume.inf_x86_neutral_29364d30156a24ca/volsnap.sys
239.6K Jul 14 2009

58df9d2481a56edde167e51b334d44fd /mnt/sda3/Windows/winsxs/x86_volume.inf_31bf3856ad364e35_6.1.7600.16385_none_158d0da45d68903e/volsnap.sys
239.6K Jul 14 2009



================ Minidump.zip=======================
(For some reason, there's an attachment bar below the message now. There wasn't one before)
Attached File  Minidump.zip   49.49KB   2 downloads


================ BSOD Message=======================
*** STOP: 0x0000007B (0x80786B58, 0xC0000034, 0x00000000, 0x00000000)

#10 JSntgRvr

JSntgRvr

    Master Surgeon General


  • Malware Response Team
  • 11,453 posts
  • OFFLINE
  •
  • Gender:Male
  • Location:Puerto Rico
  • Local time:12:01 PM

Posted 23 May 2011 - 10:33 PM

Lets write a new boot record.

  • Put the Windows Vista or Windows 7 installation disc in the disc drive, and then start the computer.
  • Press a key when you are prompted.
  • Select a language, a time, a currency, a keyboard or an input method, and then click Next.
  • Click Repair your computer.
  • Click the operating system that you want to repair, and then click Next.
  • In the System Recovery Options dialog box, click Command Prompt.
  • At the prompt type the following and press Enter after each line:

    Bootrec /FixBoot
    Bootrec /FixMbr
    Exit


If successful, restart in Normal Mode.

No request for help throughout private messaging will be attended.

If I have helped you, consider making a donation to help me continue the fight against Malware!


#11 RayN81

RayN81
  • Topic Starter

  • Members
  • 42 posts
  • OFFLINE
  •
  • Local time:02:01 AM

Posted 24 May 2011 - 12:03 AM

Hi JSntgRvr

Looks like I'm back to square one. I can't access the C: at all.
When I boot from the windows installation disk and select repair computer, I see the following:
Posted Image

There is no option for me to select.

When I go to the command prompt and type C:, I see the following:
Posted Image

I have tried running bootrec commands (/fixmbr, /fixboot, /rebuildbcd) from the command prompt, but they don't work because they say there is no drive with a boot sector attached.

#12 RayN81

RayN81
  • Topic Starter

  • Members
  • 42 posts
  • OFFLINE
  •
  • Local time:02:01 AM

Posted 24 May 2011 - 12:48 AM

Perhaps this would be a better view. From the Windows Recovery Option (picture 1 above), if I click Load Drivers, this is what I will see if I click on Computer.

Posted Image

#13 JSntgRvr

JSntgRvr

    Master Surgeon General


  • Malware Response Team
  • 11,453 posts
  • OFFLINE
  •
  • Gender:Male
  • Location:Puerto Rico
  • Local time:12:01 PM

Posted 24 May 2011 - 06:41 AM

Lets run TestDisk:

  • Download xPUDtestdisk.exe and save it to the USB device
  • Double click xPUDtestdisk.exe to extract the contents to your USB device
  • Remove the USB and insert it in the ailing computer
  • Boot the ailing computer to xPUD
  • A Welcome to xPUD screen will appear
  • Click the File
  • Expand mnt icon on the left
  • sda1,2...usually corresponds to your HDD
  • sdb1 is likely your USB
  • Click on the folder that represents your USB drive (sdb1 ?)
  • Press Tool at the top
  • Choose Open Terminal
  • Type testdisk/testdisk_static
  • Press Enter
  • The TestDisk command window will open
  • Choose Create and press Enter
  • TestDisk will now detect all local hard drives
  • Use the arrow (up and down) keys to highlight the disk called /dev/sda if it represents your primary hard drive and press Enter
  • If your not sure then note everything you see and post it for my review
  • Select [Intel] and press Enter
  • Select [Analyse] and press Enter, then press Enter again to run a [Quick Search]
  • When complete, press Enter to continue, then select [Deeper Scan] and press Enter.
  • When the deeper search completes, press Q repeatedly until TestDisk closes.
  • Close the Terminal Window
  • Remove the flash drive and put it back in the working computer, then post the contents of (or attach) the testdisk.log file on the flash drive.

No request for help throughout private messaging will be attended.

If I have helped you, consider making a donation to help me continue the fight against Malware!


#14 RayN81

RayN81
  • Topic Starter

  • Members
  • 42 posts
  • OFFLINE
  •
  • Local time:02:01 AM

Posted 24 May 2011 - 05:30 PM

Hi JSntgRvr



Tue May 24 20:44:37 2011
Command line: TestDisk

TestDisk 6.12-WIP, Data Recovery Utility, April 2010
Christophe GRENIER <grenier@cgsecurity.org>
http://www.cgsecurity.org
OS: Linux, kernel 2.6.31.2 (#5 SMP Mon Dec 7 11:56:35 UTC 2009) i686
Compiler: GCC 4.4 - Jul 27 2010 17:00:22
ext2fs lib: 1.41.9, ntfs lib: 10:0:0, reiserfs lib: 0.3.1-rc8, ewf lib: 20080501
/dev/sda: LBA, HPA, LBA48, DCO support
/dev/sda: size 3907029168 sectors
/dev/sda: user_max 3907029168 sectors
/dev/sda: native_max 3907029168 sectors
/dev/sda: dco 3907029168 sectors
Warning: can't get size for Disk /dev/mapper/control - 0 B - CHS 1 1 1, sector size=512
/dev/sr0 is not an ATA disk
Hard disk list
Disk /dev/sda - 2000 GB / 1863 GiB - CHS 243201 255 63, sector size=512 - ATA WDC WD20EARS-00M
Disk /dev/sdb - 256 MB / 245 MiB - CHS 980 16 32, sector size=512 - VBTM Store 'n' Go
Disk /dev/sr0 - 67 MB / 64 MiB - CHS 32770 1 1 (RO), sector size=2048 - PIONEER BD-ROM BDC-202

Partition table type (auto): Intel
Disk /dev/sda - 2000 GB / 1863 GiB - ATA WDC WD20EARS-00M
Partition table type: Intel

Analyse Disk /dev/sda - 2000 GB / 1863 GiB - CHS 243201 255 63
Geometry from i386 MBR: head=255 sector=63
check_part_i386 1 type 42: no test
check_part_i386 2 type 42: no test
check_part_i386 3 type 42: no test
check_part_i386 4 type 42: no test
get_geometry_from_list_part_aux head=255 nbr=1
get_geometry_from_list_part_aux head=8 nbr=1
get_geometry_from_list_part_aux head=16 nbr=1
get_geometry_from_list_part_aux head=32 nbr=1
get_geometry_from_list_part_aux head=64 nbr=1
get_geometry_from_list_part_aux head=128 nbr=1
get_geometry_from_list_part_aux head=240 nbr=1
get_geometry_from_list_part_aux head=255 nbr=1
Current partition structure:
1 P W2K Dynamic/SFS 0 1 1 0 32 32 1985
2 * W2K Dynamic/SFS 0 32 33 12 223 19 204800
3 P W2K Dynamic/SFS 12 223 20 12748 86 10 204595200
4 P W2K Dynamic/SFS 12748 86 11 243201 48 31 3702225072
Computes LBA from CHS for Disk /dev/sda - 2000 GB / 1863 GiB - CHS 243202 255 63
Allow partial last cylinder : Yes
search_vista_part: 1

search_part()
Disk /dev/sda - 2000 GB / 1863 GiB - CHS 243202 255 63
NTFS at 0/32/33
filesystem size 204800
sectors_per_cluster 8
mft_lcn 8533
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 0 32 33 12 223 19 204800 [System Reserved]
NTFS, 104 MB / 100 MiB
NTFS at 12/223/20
filesystem size 204595200
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 12 223 20 12748 86 10 204595200 [Carpathia]
NTFS, 104 GB / 97 GiB
NTFS at 12748/86/11
filesystem size 204800000
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 12748 86 11 25496 139 51 204800000 [Andorra]
NTFS, 104 GB / 97 GiB
NTFS at 25496/139/52
filesystem size 1064960000
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 25496 139 52 91787 61 50 1064960000
NTFS, 545 GB / 507 GiB
NTFS at 91787/61/51
filesystem size 1216231424
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 91787 61 51 167494 37 31 1216231424 [Games]
NTFS, 622 GB / 579 GiB
NTFS at 167494/37/32
filesystem size 1216231424
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 167494 37 32 243201 13 12 1216231424 [Downloads]
NTFS, 622 GB / 579 GiB

Results
HPFS - NTFS 0 32 33 12 223 19 204800 [System Reserved]
NTFS, 104 MB / 100 MiB
HPFS - NTFS 12 223 20 12748 86 10 204595200 [Carpathia]
NTFS, 104 GB / 97 GiB
HPFS - NTFS 12748 86 11 25496 139 51 204800000 [Andorra]
NTFS, 104 GB / 97 GiB
HPFS - NTFS 25496 139 52 91787 61 50 1064960000
NTFS, 545 GB / 507 GiB
HPFS - NTFS 91787 61 51 167494 37 31 1216231424 [Games]
NTFS, 622 GB / 579 GiB
HPFS - NTFS 167494 37 32 243201 13 12 1216231424 [Downloads]
NTFS, 622 GB / 579 GiB

interface_write()

No partition found or selected for recovery

search_part()
Disk /dev/sda - 2000 GB / 1863 GiB - CHS 243202 255 63
NTFS at 0/32/33
filesystem size 204800
sectors_per_cluster 8
mft_lcn 8533
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 0 32 33 12 223 19 204800 [System Reserved]
NTFS, 104 MB / 100 MiB
NTFS at 12/223/19
filesystem size 204800
sectors_per_cluster 8
mft_lcn 8533
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 0 32 33 12 223 19 204800 [System Reserved]
NTFS found using backup sector!, 104 MB / 100 MiB
NTFS at 12/223/20
filesystem size 204595200
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 12 223 20 12748 86 10 204595200 [Carpathia]
NTFS, 104 GB / 97 GiB
FAT32 at 1660/213/32
FAT1 : 32-4102
FAT2 : 4103-8173
start_rootdir : 8174 root cluster : 2
Data : 8174-4176829
sectors : 4176837
cluster_size : 8
no_of_cluster : 521082 (2 - 521083)
fat_length 4071 calculated 4071
FAT differs, FAT sectors=0-16/4071
set_FAT_info: name from BS used

FAT32 at 1660/213/32
FAT32 LBA 1660 213 26 1920 212 25 4176837 [NO NAME]
FAT found using backup sector!, 2138 MB / 2039 MiB
NTFS at 12748/86/10
filesystem size 204595200
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 12 223 20 12748 86 10 204595200 [Carpathia]
NTFS found using backup sector!, 104 GB / 97 GiB
NTFS at 12748/86/11
filesystem size 204800000
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 12748 86 11 25496 139 51 204800000 [Andorra]
NTFS, 104 GB / 97 GiB
NTFS at 25496/139/51
filesystem size 204800000
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 12748 86 11 25496 139 51 204800000 [Andorra]
NTFS found using backup sector!, 104 GB / 97 GiB
NTFS at 25496/139/52
filesystem size 1064960000
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 25496 139 52 91787 61 50 1064960000
NTFS, 545 GB / 507 GiB
NTFS at 91787/61/50
filesystem size 1064960000
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 25496 139 52 91787 61 50 1064960000
NTFS found using backup sector!, 545 GB / 507 GiB
NTFS at 91787/61/51
filesystem size 1216231424
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 91787 61 51 167494 37 31 1216231424 [Games]
NTFS, 622 GB / 579 GiB
NTFS at 167494/37/31
filesystem size 1216231424
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 91787 61 51 167494 37 31 1216231424 [Games]
NTFS found using backup sector!, 622 GB / 579 GiB
NTFS at 167494/37/32
filesystem size 1216231424
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 167494 37 32 243201 13 12 1216231424 [Downloads]
NTFS, 622 GB / 579 GiB
NTFS at 243201/13/12
filesystem size 1216231424
sectors_per_cluster 8
mft_lcn 786432
mftmirr_lcn 2
clusters_per_mft_record -10
clusters_per_index_record 1
HPFS - NTFS 167494 37 32 243201 13 12 1216231424 [Downloads]
NTFS found using backup sector!, 622 GB / 579 GiB

Results
HPFS - NTFS 0 32 33 12 223 19 204800 [System Reserved]
NTFS, 104 MB / 100 MiB
HPFS - NTFS 12 223 20 12748 86 10 204595200 [Carpathia]
NTFS, 104 GB / 97 GiB
FAT32 LBA 1660 213 26 1920 212 25 4176837 [NO NAME]
FAT found using backup sector!, 2138 MB / 2039 MiB
HPFS - NTFS 12748 86 11 25496 139 51 204800000 [Andorra]
NTFS, 104 GB / 97 GiB
HPFS - NTFS 25496 139 52 91787 61 50 1064960000
NTFS, 545 GB / 507 GiB
HPFS - NTFS 91787 61 51 167494 37 31 1216231424 [Games]
NTFS, 622 GB / 579 GiB
HPFS - NTFS 167494 37 32 243201 13 12 1216231424 [Downloads]
NTFS, 622 GB / 579 GiB

interface_write()

No partition found or selected for recovery
simulate write!

write_mbr_i386: starting...
write_all_log_i386: starting...
No extended partition

TestDisk exited normally.


Attached is the testdisk.log file:
Attached File  testdisk.log   9.71KB   3 downloads

Edited by JSntgRvr, 24 May 2011 - 05:46 PM.


#15 JSntgRvr

JSntgRvr

    Master Surgeon General


  • Malware Response Team
  • 11,453 posts
  • OFFLINE
  •
  • Gender:Male
  • Location:Puerto Rico
  • Local time:12:01 PM

Posted 24 May 2011 - 05:55 PM

I will have a colleague check this report.

Meanwhile, in xPUD, lets attempt to obtain a backup of the MBR once again. This time use the following process and let me know if the file size is 0.

  • Click on the folder that represents your USB drive (sdb1 ?)
  • Confirm that you see the files in your USB drive.
  • Press Tool at the top
  • Choose Open Terminal
  • Type dd if=/dev/sda of=mbr.bin bs=512 count=1


    Leave a space among the following Statements:

    dd is the executable application used to create the backup
    if=/dev/sda is the device the backup is created from - the hard drive when only one HDD exists
    of=mbr.bin is the backup file to create - note the lack of a path - it will be created in the directory currently open in the Terminal
    bs=512 is the number of bytes in the backup
    count=1 says to backup just 1 sector


    It is extremely important that the if and of statements are correctly entered.

  • Press Enter
  • After it has finished a report will be located on your USB drive named mbr.bin
  • zip that file and attach it to a reply

No request for help throughout private messaging will be attended.

If I have helped you, consider making a donation to help me continue the fight against Malware!





0 user(s) are reading this topic

0 members, 0 guests, 0 anonymous users
